Description
BRITISH GENERAL FORTRESS 100A 100MA DP TYPE A RCD
WHAT'S IN THE BOX
- 1x BRITISH GENERAL FORTRESS 100A 100MA DP TYPE A RCD (531XF)
NOTES FROM MT EXPERT
DIN Rail Mounted Fitting
OVERVIEW
BRITISH GENERAL FORTRESS 100A 100MA DP TYPE A RCD (531XF)
Use with BG Fortress consumer units for protection from earth leakage faults. Features positive contact status indication and device lock, offering capability to lock in 'on' or 'off' position.
- DIN Rail Mounted Fitting
- Type A Curve
- Double Pole
- 2 Module
| Brand | British General |
| Breaking Capacity (Inc) | 6 kA |
| CSU Device | RCDs |
| Curve Type | Type A |
| Earth Leakage Sensitivity (IDn) | 100 mA |
| Incomer Fitting Type | DIN Rail Mounted |
| Manufacturer Guarantee | 1 Year Guarantee |
| Model Name | Fortress |
| Model No | CUR100100A |
| No. of Phases | Single-Phase |
| Number of Poles | Double Pole |
| Pack Size | 1 |
| Pieces in Pack/Case | 1 |
| Product Type | RCD |
| Rated Impulse Withstand Voltage (Uimp) | 4 kV |
| Rated Operational Current (In) | 100 A |
| Rated Operational Voltage (Ue) | 230 V AC |
| Suitable Cable Size | 35 mm |
