Description
PROJECT EV TETHERED PRO EARTH 1 PORT 7.3KW MODE 3 TYPE 2 SOCKET ELECTRIC VEHICLE CHARGER BLACK
WHAT'S IN THE BOX
- 1x PROJECT EV TETHERED PRO EARTH 1 PORT 7.3KW MODE 3 TYPE 2 SOCKET ELECTRIC VEHICLE CHARGER BLACK (966JP)
NOTES FROM MT EXPERT
Reverse Polarity, Short Circuit, Overload & Low Voltage Protection
OVERVIEW
PROJECT EV TETHERED PRO EARTH 1 PORT 7.3KW MODE 3 TYPE 2 SOCKET ELECTRIC VEHICLE CHARGER BLACK (966JP)
Single-phase tethered AC electric vehicle charger, ideal for domestic use. Compact sleek design and solar compatiblity. Integrated cable locking feature to ensure total protection, granting safety and convenience tethering the charger, cable and vehicle all together securely.
- Works with - iOS App - Android App
- 230V AC Charging
- 5m Type 2 Tethered Cable
- Reverse Polarity, Short Circuit, Overload & Low Voltage Protection
- Weather-Resistant
- IP65
- Must be Fitted by a Qualified and Registered Installer
- IK10 Impact Resistance
- Solar Compatibility
- Internet Connection Required
| SPECIFICATION | |
|---|---|
| AC/DC Voltage & Charging | 230V AC Charging |
| Brand | Project EV |
| Cable Entry Points | Bottom Only |
| Charging Mode | Mode 3 |
| Colour | Black |
| Communication Protocol | OCPP |
| Compatible with Solar Panels | Compatible with Solar Panels |
| Construction Material (Electrical) | Aluminium |
| Current Rating | 32 A |
| Display Type | Without Display |
| Domestic/Commercial Use | Suitable for Domestic & Commercial Use |
| EV Plug Type | Type 2 |
| EV Product Type | Stations |
| Fitting Requirements | Must be Fitted by a Qualified and Registered Installer |
| Frequency Band (Smart) | 2.4 GHz |
| Hertz (Hz) | 50 / 60 Hz |
| IK Rating | IK10 |
| IP Rating | IP65 |
| Manufacturer Guarantee | 1 Year Guarantee |
| Model Name | Tethered Pro Earth |
| Model No | PEVEVA07SPE |
| Mount Type | Wall-Mountable |
| Network Standards | 802.11b/g/n |
| No. of Phases | Single-Phase |
| No. of Ports | 1 Port |
| Pack Size | 1 |
| Parent Colour | Black |
| Pieces in Pack/Case | 1 |
| Plug Type | Type 2 Socket |
| Power Rating (Watts Kw) | 7.3 kW |
| Power Type | Mains-Powered |
| Product Depth | 144 mm |
| Product Height | 380 mm |
| Product Type | Electric Vehicle Charger |
| Product Width | 240 mm |
| RFID Card Included | RFID Card Not Supplied |
| Resistant Type | Weather-Resistant |
| Smart Hub Requirement | Internet Connection Required |
| Standby Power Consumption | 8 W |
| Switched/Unswitched | Unswitched |
| Temperature Range | -25 to 50 °C |
| Total Product Weight | 5 kg |
| Wireless Range (Max.) | 30m |
| Wireless Range Restrictions | Electronic interference from appliances or physical obstruction, such as brick walls, metal frames and floors, can reduce the wireless range. A signal weakens every time it encounters an obstruction. |
| Works with Amazon Alexa | Does Not Work with Amazon Alexa |
| Works with Android App | Works with Android App |
| Works with Apple HomeKit | Does Not Work with Apple HomeKit |
| Works with Google Home | Does Not Work with Google Home |
| Works with iOS App | Works with iOS App |
